Description
Teflon Tape YS7020AJ, PTFE adhesive fabric Premium Series
- Teflon tape YS7020AJ is using YS9020AJ as basic material (PTFE content is 60%), and coated with high quality silicone PSA on the back, which ensure heat resistant to 260°C and long lasting performance.
- The yellow PVC liner on the back, is used to protect the adhesive and for ease of application.
- PTFE(Teflon) is a high-molecular-weight compound consist of only Carbon and Fluorine. It is hydrophobic: neither water nor water-containing substances wet PTFE, as fluorocarbons demonstrate mitigated dispersion forces because of high electronegativity of fluorine. Compared to any solid, PTFE has the lowest coefficients.
- With these characteristics, PTFE can be used a lot for nonstick coating on fiberglass, metal, plastics and other substances, such as making Teflon tape.
Teflon Tape YS7020AJ, PTFE adhesive fabric Premium Series
| Product | Product Category | Coating |
|---|---|---|
| PTFE GLASS FABRIC SELF ADHESIVE | PREMIUM SERIE | SILICONE PSA |
| Properties | Metric | Imperial |
|---|---|---|
| Standard width Please ask for other widths | 1000 mm | 39.5 inches |
| Backing Thickness PTFE glass | 0.20 mm | 0.0079 inches |
| Total Thickness PTFE glass and Silicone PSA | 0.25mm | 0.0099 inches |
| Coated weight PTFE glass | 410 g/m² | 12.1 oz/yd² |
| Tensile Strength PTFE glass | 280 N/cm Warp | 160 lbs/inches Warp |
| 256 N/cm Warp | 146 lbs/inches Warp | |
| Adhesion | 5.7 N/cm | 52 oz/inches |
| Temperature resistance | -73 to +260 °C | -100 to +500 °F |
Click here to download the TDS of YS7020AJ-ESONE
Click here to access PTFE acrylic adhesive tape
Application of Teflon adhesive tape
Removable Insulation Jacket
Due to the super nonstick surface and high temperature resistant, Teflon Tapes are workable for applications which need to resist continuous high temperature, high corrosivity or high electric strength.
For plastic bag sealing process as an example, when hot-sealing opp bags, we need PTFE tape to resist temperature and also prevent plastics sticks on the metal.
